Connecting to the server

By default Manticore is waiting for your connections on:

  • port 9306 for MySQL clients
  • port 9308 for HTTP/HTTPS connections
  • port 9312 for connections from other Manticore nodes and clients based on Manticore binary API
📋
mysql -h0 -P9306

MySQL protocol

Manticore Search implements an SQL interface using MySQL protocol, which allows any MySQL client, library or connector to be used for connecting to Manticore Search and work with it as if it would be MySQL server, not Manticore.

However the SQL dialect is different. It implements only a subset of SQL commands or functions available in MySQL. In addition, there are clauses and functions that are specific to Manticore Search. The most eloquent example is the MATCH() clause which allows setting the full-text search.

Manticore Search doesn't support server-side prepared statements. Client-side prepared statements can be used with Manticore. It must be noted that Manticore implements the multi value (MVA) data type for which there is no equivalent in MySQL or libraries implementing prepared statements. In these cases, the MVA values will need to be crafted in the raw query.

Some MySQL clients/connectors demand values for user/password and/or database name. Since Manticore Search does not have the concept of database and there is no user access control yet implemented, these can be set arbitrarily as Manticore will simply ignore the values.

Configuration

The default port for the SQL interface is 9306 and it's enabled by default.

In the searchd section of the configuration file the MySQL port can be defined by listen directive like this:

searchd {
...
   listen = 127.0.0.1:9306:mysql
...
}

Because Manticore doesn't have yet user authentication implemented make sure the MySQL port can't be accessed by anyone outside your network.

VIP connection

A separate MySQL port can be used to perform 'VIP' connections. A connection to this port bypasses the thread pool and always forcibly creates a new dedicated thread. That's useful for managing in case of a severe overload when the server would either stall or not let you connect via a regular port.

searchd {
...
   listen = 127.0.0.1:9306:mysql
   listen = 127.0.0.1:9307:mysql_vip
...
}

Connecting via standard MySQL client

The easiest way to connect to Manticore is by using a standard MySQL client:

mysql -P9306 -h0

Secured MySQL connection

The MySQL protocol supports SSL encryption. The secured connections can be made on the same mysql listening port.

Compressed MySQL connection

Compression can be used with MySQL Connections and available to clients by default. The client just need to specify the connection to use compression.

An example with the MySQL client:

mysql -P9306 -h0 -C

Compression can be used in both secured and non-secured connections.

Notes on MySQL connectors

The official MySQL connectors can be used to connect to Manticore Search, however they might require certain settings passed in the DSN string as the connector can try running certain SQL commands not implemented yet in Manticore.

JDBC Connector 6.x and above require Manticore Search 2.8.2 or greater and the DSN string should contain the following options:

jdbc:mysql://IP:PORT/DB/?characterEncoding=utf8&maxAllowedPacket=512000&serverTimezone=XXX

By default Manticore Search will report it's own version to the connector, however this may cause some troubles. To overcome that mysql_version_string directive in searchd section of the configuration should be set to a version lower than 5.1.1:

searchd {
...
   mysql_version_string = 5.0.37
...
}

.NET MySQL connector uses connection pools by default. To correctly get the statistics of SHOW META, queries along with SHOW META command should be sent as a single multistatement (SELECT ...;SHOW META). If pooling is enabled option Allow Batch=True is required to be added to the connection string to allow multistatements:

Server=127.0.0.1;Port=9306;Database=somevalue;Uid=somevalue;Pwd=;Allow Batch=True;

Notes on ODBC connectivity

Manticore can be accessed using ODBC. It's recommended to set charset=UTF8 in the ODBC string. Some ODBC drivers will not like the reported version by the Manticore server as they will see it as a very old MySQL server. This can be overridden with mysql_version_string option.

Comment syntax

Manticore SQL over MySQL supports C-style comment syntax. Everything from an opening /* sequence to a closing */ sequence is ignored. Comments can span multiple lines, can not nest, and should not get logged. MySQL specific /*! ... */ comments are also currently ignored. (As the comments support was rather added for better compatibility with mysqldump produced dumps, rather than improving general query interoperability between Manticore and MySQL.)

SELECT /*! SQL_CALC_FOUND_ROWS */ col1 FROM table1 WHERE ...

HTTP

You can connect to Manticore Search using the HTTP protocol.

Configuration

The HTTP protocol is by default available on port 9308.

In the searchd section of the configuration file the HTTP port can be defined with directive listen like this:

searchd {
...
   listen = 127.0.0.1:9308:http
...
}

There are no special requirements and any HTTP client can be used to connect to Manticore.

All endpoints respond with application/json content type. Most endpoints use JSON payload for requests, however there are some exceptions that use NDJSON or simple URL encoded payload.

There is no user authentication implemented at the moment, so make sure the HTTP interface is not reachable by anyone outside your network. Since Manticore acts like any other web server, you can use a reverse proxy like Nginx to add HTTP auth or caching.

The HTTP protocol also supports SSL encryption.

VIP connection

A separate HTTP interface can be used to perform 'VIP' connections. A connection to this port bypasses the thread pool and always forcibly creates a new dedicated thread. That's useful for managing in case of a severe overload when the server would either stall or not let you connect via a regular port.

searchd {
...
   listen = 127.0.0.1:9308:http
   listen = 127.0.0.1:9318:http_vip
...
}

The HTTP protocol also supports SSL encryption. In this case the connection type used will be https:

searchd {
...
   listen = 127.0.0.1:9308:http
   listen = 127.0.0.1:9443:https
...
}

Connecting with cURL

Performing a quick search is as easy as:

POST /search
    -d '{"index":"test","query":{"match":{"title":"keyword"}}}'

SQL over HTTP

Endpoint /sql allows running an SQL SELECT query via HTTP JSON interface.

The query payload must be URL encoded, otherwise query statements with = (filtering or setting options) will result in an error.

POST /sql
--data-urlencode "query=select id,subject,author_id  from forum where match('@subject php manticore') group by
author_id order by id desc limit 0,5"

The response is in JSON format and contains hits information and time of execution. The response shares the same format as json/search endpoint.

{
  "took":10
  "timed_out": false,
  "hits":
  {
    "total": 2,
    "hits":
    [
      {
        "_id": "1",
        "_score": 1,
        "_source": { "gid": 11 }
      },
      {
        "_id": "2",
        "_score": 1,
        "_source": { "gid": 12 }
      }
    ]
  }
}

For comfortable debugging in your browser you can set HTTP parameter mode to raw, and then the rest of the query after 'query=' will be passed inside without any substitutions/url decoding.

POST /sql -d "query=select id,packedfactors() from movies where match('star') option ranker=expr('1')"
{"error":"query missing"}
POST /sql -d "mode=raw&query=query=select id,packedfactors() from movies where match('star') option ranker=expr('1')"
{
  "took":0,
  "timed_out":false,
  "hits":{
    "total":72,
    "hits":[
      {
        "_id":"5",
        "_score":1,
        "_source":{
          "packedfactors()":{
            "bm25":612,
            "bm25a":0.69104159,
            "field_mask":32,
            "doc_word_count":1,
            "fields":[
              {
                "field":5,
                "lcs":1,
                "hit_count":1,
                "word_count":1,
                "tf_idf":0.24835411,
                "min_idf":0.24835411,
                "max_idf":0.24835411,
                "sum_idf":0.24835411,
                "min_hit_pos":1,
                "min_best_span_pos":1,
                "exact_hit":0,
                "max_window_hits":1,
                "min_gaps":0,
                "exact_order":1,
                "lccs":1,
                "wlccs":0.24835411,
                "atc":0.000000
              }
            ],
            "words":[
              {
                "tf":1,
                "idf":0.24835411
              }
            ]
          }
        }
      },
...
    ]
  }
}
