Reporting bugs

Unfortunately, Manticore is not yet 100% bug-free (although we are working hard towards that goal). You may occasionally encounter some issues.

It is very important to report as much information as possible about each bug. To fix a bug, we need to either reproduce and fix it or deduce what is causing it based on the information you provide. Therefore, here are some instructions on how to do that.

Bug-tracker

We track bugs and feature requests on Github. Feel free to create a new ticket and describe your bug in detail so that you and the developers can save time.

Documentation updates

Updates to the documentation (what you are reading now) are also done on Github.

Crashes

Manticore is written in C++, a low-level programming language that allows for direct communication with the computer for faster performance. The drawback of that is that in rare cases, it may not be possible to elegantly handle a bug by writing an error to a log and skipping the processing of the command that caused the problem. Instead, the program may crash, which means it will stop completely and need to be restarted.

When Manticore Search crashes, you need to let the Manticore team know about it by making a bug report on GitHub, or if you use Manticore's professional services in your private helpdesk. The Manticore team needs the following information:

  1. Searchd log
  2. Coredump
  3. Query log

It will be great if you additionally do the following:

  1. Run gdb to inspect the coredump:
    gdb /usr/bin/searchd </path/to/coredump>
  2. Find crashed thread id in the coredump file name (make sure you have %p in /proc/sys/kernel/core_pattern), e.g. core.work_6.29050.server_name.1637586599 means thread_id=29050
  3. In gdb run:
    set pagination off
info threads
# find thread number by it's id (e.g. for `LWP 29050` it will be thread number 8
thread apply all bt
thread <thread number>
bt full
info locals
quit
  4. Provide the outputs

What do I do when Manticore Search hangs?

You need to run gdb manually and collect some info that may be useful to understand why it's hanging.

  1. show threads option format=all run trough a VIP port

  2. collect lsof output since hanging can be caused by too many connections or open file descriptors

    lsof -p `cat /var/run/manticore/searchd.pid`

  3. dump core

    gcore `cat /var/run/manticore/searchd.pid`

    (it will save the dump to the current dir)

  4. Install and run gdb:

    gdb /usr/bin/searchd `cat /var/run/manticore/searchd.pid`

    Note it will halt your running searchd, but if it's alredy hanging it shouldn't be a problem.

  5. In gdb run:

    set pagination off
info threads
thread apply all bt
quit

  6. Collect all the outputs and files and provide them in a bug report.

For experts: the macros added in this commit can be helpful to debug.

How to enable saving coredumps on crash?

[root@srv lib]# systemctl set-environment _ADDITIONAL_SEARCHD_PARAMS='--coredump'
[root@srv lib]# systemctl restart manticore
[root@srv lib]# ps aux|grep searchd
mantico+  1955  0.0  0.0  61964  1580 ?        S    11:02   0:00 /usr/bin/searchd --config /etc/manticoresearch/manticore.conf --coredump
mantico+  1956  0.6  0.0 392744  2664 ?        Sl   11:02   0:00 /usr/bin/searchd --config /etc/manticoresearch/manticore.conf --coredump
  • make sure that your OS allows you to save coredumps: /proc/sys/kernel/core_pattern should be non-empty - this is where it will save them. If you do:
    echo "/cores/core.%e.%p.%h.%t" > /proc/sys/kernel/core_pattern

    it will instruct your kernel to save them to file like core.searchd.1773.centos-4gb-hel1-1.1636454937

  • searchd should be started with ulimit -c unlimited, but if you start Manticore via systemctl it does it for yourself since it does:
    [root@srv lib]# grep CORE /lib/systemd/system/manticore.service
LimitCORE=infinity

How do I install debug symbols?

Manticore Search and Manticore Columnar Library are written in C++, which means that when you run them, you get a compiled, compact binary file that executes optimally on your operating system. However, when you run a binary, your system does not have full access to the names of variables, functions, methods, and classes that are implemented. All of this information is provided separately in something called "debuginfo" or "symbol packages."

Debug symbols are useful for troubleshooting and other debugging purposes, as they allow you to visualize the state of the system when it crashed, including the names of functions, when you have symbols and your binary crashes. Manticore Search provides a backtrace in the searchd log and also generates a coredump if it was run with the --coredump flag. Without symbols, all you get is internal offsets, which can be difficult or impossible to decode. Therefore, if you need to make a bug report about a crash, the Manticore team will often need debug symbols in order to help you.

To install Manticore Search/Manticore Columnar Library debug symbols, you will need to install the *debuginfo* package for CentOS, the *dbgsym* package for Ubuntu and Debian, or the *dbgsymbols* package for Windows and macOS. These packages should be of the same version as the version of Manticore that you are running. For example, if you've installed Manticore Search in Centos 8 from the package https://repo.manticoresearch.com/repository/manticoresearch/release/centos/8/x86_64/manticore-4.0.2_210921.af497f245-1.el8.x86_64.rpm , the corresponding package with symbols would be https://repo.manticoresearch.com/repository/manticoresearch/release/centos/8/x86_64/manticore-debuginfo-4.0.2_210921.af497f245-1.el8.x86_64.rpm

Note that both packages have the same commit id af497f245, which corresponds to the commit that this version was built from.

If you have installed Manticore from a Manticore APT/YUM repository, you can use one of the following tools:

  • debuginfo-install in CentOS 7
  • dnf debuginfo-install CentOS 8
  • find-dbgsym-packages in Debian and Ubuntu

to find a debug symbols package for you.

How to check the debug symbols exist?

  1. Find build id in file /usr/bin/searchd output:
[root@srv lib]# file /usr/bin/searchd
/usr/bin/searchd: ELF 64-bit LSB executable, x86-64, version 1 (GNU/Linux), dynamically linked (uses shared libs), for GNU/Linux 2.6.32, BuildID[sha1]=2c582e9f564ea1fbeb0c68406c271ba27034a6d3, stripped

In this case it's 2c582e9f564ea1fbeb0c68406c271ba27034a6d3.

  1. Find symbols in /usr/lib/debug/.build-id like this:
[root@srv ~]# ls -la /usr/lib/debug/.build-id/2c/582e9f564ea1fbeb0c68406c271ba27034a6d3*
lrwxrwxrwx. 1 root root 23 Nov  9 10:42 /usr/lib/debug/.build-id/2c/582e9f564ea1fbeb0c68406c271ba27034a6d3 -> ../../../../bin/searchd
lrwxrwxrwx. 1 root root 27 Nov  9 10:42 /usr/lib/debug/.build-id/2c/582e9f564ea1fbeb0c68406c271ba27034a6d3.debug -> ../../usr/bin/searchd.debug

Uploading your data

To fix your bug, developers often need to reproduce it locally. To do this, they need your configuration file, table files, binlog (if present), and sometimes source data (such as data from external storages or XML/CSV files) and queries.

Attach your data when you create a ticket on Github. If it is too large or the data is sensitive, you can feel free to upload it to our write-only S3 storage s3://s3.manticoresearch.com/write-only/. Here's how you can do it using Minio client:

  1. Install the client https://min.io/docs/minio/linux/reference/minio-mc.html#install-mc
  2. Add our s3 host: mc config host add manticore http://s3.manticoresearch.com:9000 manticore manticore
  3. Copy your files: mc cp -r issue-1234/ manticore/write-only/issue-1234 . Make sure you make the folder name unique, best if it corresponds to the issue on GitHub where you described the bug

DEBUG

DEBUG [ subcommand ]

DEBUG statement is designed to call different internal or vip commands for dev/testing purposes. It is not intended for production automation, since the syntax of subcommand part may be freely changed in any build.

Call DEBUG without params to show a list of useful commands (in general) and subcommands (of DEBUG statement) available at the current context.

mysql> debug;
+-------------------------------------------------------------------------+----------------------------------------------------------------------------------------+
| command                                                                 | meaning                                                                                |
+-------------------------------------------------------------------------+----------------------------------------------------------------------------------------+
| flush logs                                                              | emulate USR1 signal                                                                    |
| reload indexes                                                          | emulate HUP signal                                                                     |
| debug token <password>                                                  | calculate token for password                                                           |
| debug malloc_stats                                                      | perform 'malloc_stats', result in searchd.log                                          |
| debug malloc_trim                                                       | pefrorm 'malloc_trim' call                                                             |
| debug sleep <N>                                                         | sleep for <N> seconds                                                                  |
| debug tasks                                                             | display global tasks stat (use select from @@system.tasks instead)                     |
| debug sched                                                             | display task manager schedule (use select from @@system.sched instead)                 |
| debug merge <TBL> [chunk] <X> [into] [chunk] <Y> [option sync=1,byid=0] | For RT table <TBL> merge disk chunk X into disk chunk Y                                |
| debug drop [chunk] <X> [from] <TBL> [option sync=1]                     | For RT table <TBL> drop disk chunk X                                                   |
| debug files <TBL> [option format=all|external]                          | list files belonging to <TBL>. 'all' - including external (wordforms, stopwords, etc.) |
| debug close                                                             | ask server to close connection from it's side                                          |
| debug compress <TBL> [chunk] <X> [option sync=1]                        | Compress disk chunk X of RT table <TBL> (wipe out deleted documents)                   |
| debug split <TBL> [chunk] <X> on @<uservar> [option sync=1]             | Split disk chunk X of RT table <TBL> using set of DocIDs from @uservar                 |
| debug wait <cluster> [like 'xx'] [option timeout=3]                     | wait <cluster> ready, but no more than 3 secs.                                         |
| debug wait <cluster> status <N> [like 'xx'] [option timeout=13]         | wait <cluster> commit achieve <N>, but no more than 13 secs                            |
| debug meta                                                              | Show max_matches/pseudo_shards. Needs set profiling=1                                  |
| debug trace OFF|'path/to/file' [<N>]                                    | trace flow to file until N bytes written, or 'trace OFF'                               |
| debug curl <URL>                                                        | request given url via libcurl                                                          |
+-------------------------------------------------------------------------+----------------------------------------------------------------------------------------+
19 rows in set (0.00 sec)

Same from VIP connection:

mysql> debug;
+-------------------------------------------------------------------------+----------------------------------------------------------------------------------------+
| command                                                                 | meaning                                                                                |
+-------------------------------------------------------------------------+----------------------------------------------------------------------------------------+
| flush logs                                                              | emulate USR1 signal                                                                    |
| reload indexes                                                          | emulate HUP signal                                                                     |
| debug shutdown <password>                                               | emulate TERM signal                                                                    |
| debug crash <password>                                                  | crash daemon (make SIGSEGV action)                                                     |
| debug token <password>                                                  | calculate token for password                                                           |
| debug malloc_stats                                                      | perform 'malloc_stats', result in searchd.log                                          |
| debug malloc_trim                                                       | pefrorm 'malloc_trim' call                                                             |
| debug procdump                                                          | ask watchdog to dump us                                                                |
| debug setgdb on|off                                                     | enable or disable potentially dangerous crash dumping with gdb                         |
| debug setgdb status                                                     | show current mode of gdb dumping                                                       |
| debug sleep <N>                                                         | sleep for <N> seconds                                                                  |
| debug tasks                                                             | display global tasks stat (use select from @@system.tasks instead)                     |
| debug sched                                                             | display task manager schedule (use select from @@system.sched instead)                 |
| debug merge <TBL> [chunk] <X> [into] [chunk] <Y> [option sync=1,byid=0] | For RT table <TBL> merge disk chunk X into disk chunk Y                                |
| debug drop [chunk] <X> [from] <TBL> [option sync=1]                     | For RT table <TBL> drop disk chunk X                                                   |
| debug files <TBL> [option format=all|external]                          | list files belonging to <TBL>. 'all' - including external (wordforms, stopwords, etc.) |
| debug close                                                             | ask server to close connection from it's side                                          |
| debug compress <TBL> [chunk] <X> [option sync=1]                        | Compress disk chunk X of RT table <TBL> (wipe out deleted documents)                   |
| debug split <TBL> [chunk] <X> on @<uservar> [option sync=1]             | Split disk chunk X of RT table <TBL> using set of DocIDs from @uservar                 |
| debug wait <cluster> [like 'xx'] [option timeout=3]                     | wait <cluster> ready, but no more than 3 secs.                                         |
| debug wait <cluster> status <N> [like 'xx'] [option timeout=13]         | wait <cluster> commit achieve <N>, but no more than 13 secs                            |
| debug meta                                                              | Show max_matches/pseudo_shards. Needs set profiling=1                                  |
| debug trace OFF|'path/to/file' [<N>]                                    | trace flow to file until N bytes written, or 'trace OFF'                               |
| debug curl <URL>                                                        | request given url via libcurl                                                          |
+-------------------------------------------------------------------------+----------------------------------------------------------------------------------------+
24 rows in set (0.00 sec)

All debug XXX commands should be regarded as non-stable and subject to modification at any time, so don't be surprised if they change. This example output may not reflect the actual available commands, so try it on your system to see what is available on your instance. Additionally, there is no detailed documentation provided aside from this short 'meaning' column.

As a quick illustration, two commands available only to VIP clients are described below - shutdown and crash. Both require a token, which can be generated with the debug token subcommand, and added to the shutdown_token param in the searchd section of the config file. If no such section exists, or if the provided password hash does not match the token stored in the config, the subcommands will do nothing.

mysql> debug token hello;
+-------------+------------------------------------------+
| command     | result                                   |
+-------------+------------------------------------------+
| debug token | aaf4c61ddcc5e8a2dabede0f3b482cd9aea9434d |
+-------------+------------------------------------------+
1 row in set (0,00 sec)

The subcommand shutdown will send a TERM signal to the server, causing it to shut down. This can be dangerous, as nobody wants to accidentally stop a production service. Therefore, it requires a VIP connection and the password to be used.

The subcommand crash literally causes a crash. It may be used for testing purposes, such as to test how the system manager maintains the service's liveness or to test the feasibility of tracking coredumps.

If some commands are found to be useful in a more general context, they may be moved from the debug subcommands to a more stable and generic location (as exemplified by the debug tasks and debug sched in the table).
