Reporting bugs

Unfortunately, Manticore is not yet 100% bug free (even though we're working hard towards that), so you might occasionally run into some issues.

Reporting as much as possible about each bug is very important - because to fix it, we need to be able to either reproduce and fix the bug, or to deduce what's causing it from the information that you provide. So here are some instructions how to do that.

Bug-tracker

We track bugs and feature requests in Github. Feel free to create a new ticket and describe your bug in details so both you and developers can save their time.

Documentation updates

Updates to the documentation (what you are reading now) is also done on Github.

Crashes

Manticore is written in C++ - low level programming language allowing to speak to the computer with not so many intermediate layers for faster performance. The drawback of that is that in rare cases there is no way to handle a bug elegantly writing the error about it to a log and skipping processing the command which caused the problem. Instead of that the program can just crash which means it would stop completely and would have to be restarted.

In case of crashes we sometimes can get enough info to fix from the backtrace which Manticore tries to write down in the log file. It might look like this:

./indexer(_Z12sphBacktraceib+0x2d6)[0x5d337e]
./indexer(_Z7sigsegvi+0xbc)[0x4ce26a]
/lib64/libpthread.so.0[0x3f75a0dd40]
/lib64/libc.so.6(fwrite+0x34)[0x3f74e5f564]
./indexer(_ZN27CSphCharsetDefinitionParser5ParseEPKcR10CSphVectorI14CSphRemapRange16CSphVe
ctorPolicyIS3_EE+0x5b)[0x51701b]
./indexer(_ZN13ISphTokenizer14SetCaseFoldingEPKcR10CSphString+0x62)[0x517e4c]
./indexer(_ZN17CSphTokenizerBase14SetCaseFoldingEPKcR10CSphString+0xbd)[0x518283]
./indexer(_ZN18CSphTokenizer_SBCSILb0EEC1Ev+0x3f)[0x5b312b]
./indexer(_Z22sphCreateSBCSTokenizerv+0x20)[0x51835c]
./indexer(_ZN13ISphTokenizer6CreateERK21CSphTokenizerSettingsPK17CSphEmbeddedFilesR10CSphS
tring+0x47)[0x5183d7]
./indexer(_Z7DoIndexRK17CSphConfigSectionPKcRK17SmallStringHash_TIS_EbP8_IO_FILE+0x494)[0x
4d31c8]
./indexer(main+0x1a17)[0x4d6719]
/lib64/libc.so.6(__libc_start_main+0xf4)[0x3f74e1d8a4]
./indexer(__gxx_personality_v0+0x231)[0x4cd779]

This was an example of a good backtrace - we can see mangled function names here.

But sometimes backtrace may look like this:

/opt/piler/bin/indexer[0x4c4919]
/opt/piler/bin/indexer[0x405cf0]
/lib/x86_64-linux-gnu/libpthread.so.0(+0xfcb0)[0x7fc659cb6cb0]
/opt/piler/bin/indexer[0x4237fd]
/opt/piler/bin/indexer[0x491de6]
/opt/piler/bin/indexer[0x451704]
/opt/piler/bin/indexer[0x40861a]
/opt/piler/bin/indexer[0x40442c]
/lib/x86_64-linux-gnu/libc.so.6(__libc_start_main+0xed)[0x7fc6588aa76d]
/opt/piler/bin/indexer[0x405b89]

Developers might not get anything useful from these cryptic numbers since it doesn't show function names. To help that you need to provide symbols (function and variable names). If you've installed Manticore by building from sources, run the following command over your binary:

nm -n indexer > indexer.sym

Attach this file to a bug report along with backtrace. You should however ensure that the binary is not stripped. Our official binary packages should be fine. However, if you built Manticore manually from sources, do not run strip utility on that binary, and/or do not let your build/packaging system do that, otherwise the symbols will be lost completely.

In some cases crashes can happen, because the index files have a corruption. It's highly recommended to use indextool --check and add the output to the bug report you will create on Github.

Core dumps

A core dump is a file containing a process's address space (memory) when the process terminates unexpectedly.

Sometimes the backtrace doesn't provide enough information about the cause of a crash or the crash cannot be easily reproduced and core files are required for troubleshooting.

For searchd (Manticore search server) to record a core dump in case of a crash, the following needs to be ensured:

  • core dumping needs to be enabled on the running operating system. Some operating systems do not have core dumping enabled by default
  • searchd needs to be started with --coredump option

Please note that searchd core files can use a lot of space as they include data from the loaded indexes and each crash creates a new core file. Free space should be monitored while searchd runs with --coredump option enabled to avoid 100% disk usage.

Hanging

In case Manticore is hanging for some reason and

  1. the instance is under watchdog (which is on by default)
  2. gdb is installed

Then:

  • either connect to the instance via mysql (vip or regular port) and issue debug procdump
  • or manually send USR2 signal to watchdog of the hanging instance (not to the instance process itself)
  • or manually run gdb attach <PID_of_hanged> and then these commands one by one:
    1. info threads
    2. thread apply all bt
    3. bt
    4. info locals
    5. detach

In the first 2 cases trace will be in the server's log. In the last (manual gdb) case it has to be copied from console output. These traces need to be attached, it will be very helpful for investigation.

Uploading your data

To fix your bug developers often need to reproduce it locally. To do it they need your configuration file, index files, binlog (if present), sometimes data to index (like data from external storages or XML/CSV files) and queries.

Attach your data when you create a ticket on Github. In case it's too big or the data is sensitive feel free to upload it to our write-only FTP server:

  • ftp: dev.manticoresearch.com
  • user: manticorebugs
  • pass: shithappens
  • directory: create directory github-issue-N so we understand what data is related with what issue on Github.

It's convenient to mirror your directory with our FTP using tool lftp which is available for Linux, Mac and Windows. For example, if you want to sync your current directory ftp to directory github-ussue-123, here's what you should do and what you will get:

➜  ~ lftp -e "mkdir github-issue-123; mirror -LR ftp/ github-issue-123/" -u manticorebugs,shithappens dev.manticoresearch.com
mkdir ok, `github-issue-123' created
Total: 2 directories, 1 file, 0 symlinks
New: 1 file, 0 symlinks
lftp manticorebugs@dev.manticoresearch.com:/> quit

DEBUG

DEBUG [ subcommand ]

DEBUG statement is designed to call different internal or vip commands for dev/testing purposes. It is not intended for production automation, since the syntax of subcommand part may be freely changed in any build.

Call DEBUG without params to show list of useful commands (in general) and subcommands (of DEBUG statement) available at the moment.

However you can invoke DEBUG without params to know which subcommands of the statement are available in any particular case:

MySQL [(none)]> debug;
+------------------------------------------------------------------+----------------------------------------------------------------------------------------+
| command                                                          | meaning                                                                                |
+------------------------------------------------------------------+----------------------------------------------------------------------------------------+
| flush logs                                                       | emulate USR1 signal                                                                    |
| reload indexes                                                   | emulate HUP signal                                                                     |
| debug token <password>                                           | calculate token for password                                                           |
| debug malloc_stats                                               | perform 'malloc_stats', result in searchd.log                                          |
| debug malloc_trim                                                | pefrorm 'malloc_trim' call                                                             |
| debug sleep <N>                                                  | sleep for <N> seconds                                                                  |
| debug tasks                                                      | display global tasks stat (use select from @@system.tasks instead)                     |
| debug systhreads                                                 | display task manager threads (use select from @@system.systhreads instead)             |
| debug sched                                                      | display task manager schedule (use select from @@system.sched instead)                 |
| debug merge <IDX> [chunk] <X> [into] [chunk] <Y> [option sync=1] | For RT index <IDX> merge disk chunk X into disk chunk Y                                |
| debug drop [chunk] <X> [from] <IDX> [option sync=1]              | For RT index <IDX> drop disk chunk X                                                   |
| debug files <IDX> [option format=all|external]                   | list files belonging to <IDX>. 'all' - including external (wordforms, stopwords, etc.) |
| debug close                                                      | ask server to close connection from it's side                                          |
| debug compress <IDX> [chunk] <X> [option sync=1]                 | Compress disk chunk X of RT index <IDX> (wipe out deleted documents)                   |
| debug split <IDX> [chunk] <X> on @<uservar> [option sync=1]      | Split disk chunk X of RT index <IDX> using set of DocIDs from @uservar                 |
+------------------------------------------------------------------+----------------------------------------------------------------------------------------+
15 rows in set (0.00 sec)

(these commands are already documented, but such short help just remind about them).

If you connect via 'VIP' connection (see listen for details) the output might be a bit different:

MySQL [(none)]> debug;
+------------------------------------------------------------------+----------------------------------------------------------------------------------------+
| command                                                          | meaning                                                                                |
+------------------------------------------------------------------+----------------------------------------------------------------------------------------+
| flush logs                                                       | emulate USR1 signal                                                                    |
| reload indexes                                                   | emulate HUP signal                                                                     |
| debug shutdown <password>                                        | emulate TERM signal                                                                    |
| debug crash <password>                                           | crash daemon (make SIGSEGV action)                                                     |
| debug token <password>                                           | calculate token for password                                                           |
| debug malloc_stats                                               | perform 'malloc_stats', result in searchd.log                                          |
| debug malloc_trim                                                | pefrorm 'malloc_trim' call                                                             |
| debug procdump                                                   | ask watchdog to dump us                                                                |
| debug setgdb on|off                                              | enable or disable potentially dangerous crash dumping with gdb                         |
| debug setgdb status                                              | show current mode of gdb dumping                                                       |
| debug sleep <N>                                                  | sleep for <N> seconds                                                                  |
| debug tasks                                                      | display global tasks stat (use select from @@system.tasks instead)                     |
| debug systhreads                                                 | display task manager threads (use select from @@system.systhreads instead)             |
| debug sched                                                      | display task manager schedule (use select from @@system.sched instead)                 |
| debug merge <IDX> [chunk] <X> [into] [chunk] <Y> [option sync=1] | For RT index <IDX> merge disk chunk X into disk chunk Y                                |
| debug drop [chunk] <X> [from] <IDX> [option sync=1]              | For RT index <IDX> drop disk chunk X                                                   |
| debug files <IDX> [option format=all|external]                   | list files belonging to <IDX>. 'all' - including external (wordforms, stopwords, etc.) |
| debug close                                                      | ask server to close connection from it's side                                          |
| debug compress <IDX> [chunk] <X> [option sync=1]                 | Compress disk chunk X of RT index <IDX> (wipe out deleted documents)                   |
| debug split <IDX> [chunk] <X> on @<uservar> [option sync=1]      | Split disk chunk X of RT index <IDX> using set of DocIDs from @uservar                 |
+------------------------------------------------------------------+----------------------------------------------------------------------------------------+
20 rows in set (0.00 sec)

Here you can see additional commands available only in the current context (namely, if you connected on a VIP port). Two additional subcommands available right now are token and shutdown. The first one just calculates a hash (SHA1) of the (which, in turn, may be empty, or a word, or num/phrase enclosed in '-quotes) like:

mysql> debug token hello;
+-------------+------------------------------------------+
| command     | result                                   |
+-------------+------------------------------------------+
| debug token | aaf4c61ddcc5e8a2dabede0f3b482cd9aea9434d |
+-------------+------------------------------------------+
1 row in set (0,00 sec)

Another debug subcommand shutdown will send a TERM signal to the server and so will make it shut down. Since it is quite dangerous (nobody wants accidentally stop a production service), it:

  1. needs a VIP connection, and
  2. needs the password

For the chosen password you need to generate a token with debug token subcommand, and put it into shutdown_token param of searchd section of the config file. If no such section exists, or if a hash of the provided password does not match with the token stored in the config, the subcommand will do nothing. Otherwise it will cause 'clean' shutdown of the server.
